Gobel Power GP-12300 12.8V 300Ah 3.84kWh LiFePO4 Battery Pack - Deep Cycle Solar Battery with Built-in BMS, ABS Case, 4000+ Cycles for RV, Marine, Off-Grid Solar

Model Number:
GP-12300
Case Material:
ABS
Nominal Capacity:
300Ah
Nominal Voltage:
12.8V
Size:
522*240*218mm
Weight:
29kg
Working temperature:
-20~70℃
EU & US Local Warehouses
Fast DDP delivery in 3-7 days
Up to 10-Year Warranty
Industry-leading coverage, 6000+ cycles
Certified Safety
CE / UN38.3 / MSDS certified
Product Introduction
  Gobel Power GP-12300 · 12.8V 300Ah 3.84kWh

GP-12300 12.8V 300Ah 3.84kWh Deep Cycle LiFePO4 Battery

Engineered for high-capacity power storage with a durable ABS enclosure, premium cobalt-free LiFePO4 cells, and an integrated smart BMS. Delivering a massive 3.84kWh energy capacity for reliable RV, marine, trolling motor, and off-grid solar energy storage.

3.84 kWhUsable Energy12.8V / 300AhVoltage & Capacity200AMax Discharge4,000+Cycle Lifespan
High Capacity & Energy Density

3.84kWh Massive Power in a Compact 29kg Lightweight Design

The Gobel Power GP-12300 replaces bulky traditional lead-acid battery banks with high-energy-density LiFePO4 chemistry, offering more usable power in a lighter, space-saving format.

  • Massive Single-Module Power: 300Ah capacity delivers 3.84kWh energy to run high-load appliances and inverters effortlessly.

  • Low Self-Discharge & Efficiency: High round-trip efficiency (≥90%) ensures minimal power loss during charging and discharging.

  • Durable ABS Case: Rugged outer shell provides excellent physical protection for mobile RV, marine, and off-grid environments.

Built-in Intelligent BMS & Multi-Layer Safety Guard

Equipped with an internal automated Battery Management System (BMS) that monitors internal parameters in real-time to protect against potential electrical damage.

  • Automated BMS Protection: Guarantees protection against cell overvoltage (3.8V), undervoltage (2.3V), short circuit, and overcurrent.

  • High Current Capability: Supports up to 200A continuous discharge and 100A continuous charge current for demanding power needs.

  • Safe LFP Chemistry: Cobalt-free Lithium Iron Phosphate chemistry offers superior thermal stability and safety standard testing.

Flexible Scalability Up to 4S8P for Higher Voltage & Capacity

Easily configure your battery bank to match your specific power requirements through multi-battery series and parallel connections.

  • Up to 4S Connection: Connect up to 4 units in series to build a 51.2V nominal voltage system.

  • Up to 8P Connection: Expand in parallel up to 8 units for huge capacity expansion up to 2,400Ah (30.72kWh).

  • 4,000+ Deep Cycles: Provides long service life with over 4,000 cycles at 80% DOD for decades of reliable use.

Versatile Applications for Mobile & Stationary Power Needs

Designed as a multi-purpose deep-cycle battery for various indoor, off-grid, and mobile energy setups.

  • RVs & Campers: Reliable house power bank to run AC, refrigeration, and electronics on long off-grid trips.

  • Marine & Trolling Motors: Heavy-duty, lightweight power source for boats and trolling motor applications.

  • Off-Grid Solar ESS: Ideal main or backup battery bank for off-grid cabins, solar systems, and emergency backup.

Technical Specifications

Product ModelGobel Power GP-12300
Nominal Energy / Usable Capacity3.84 kWh
Nominal Voltage / Operating Range12.8 VDC (10.0V – 14.6V)
Nominal Capacity & Cell Type300Ah Prismatic LiFePO4 (Cobalt-Free)
Max Continuous Charge Current100A
Max Continuous Discharge Current200A
Internal Resistance<80 mΩ (AC at 1000Hz)
Cycle Life & Efficiency≥4,000 Cycles @ 80% DOD | ≥90% Energy Efficiency
ScalabilitySupports Up to 4S and 8P Connection (4S8P)
Enclosure Material & DimensionsABS Case | 522mm x 240mm x 218mm (Weight: 29kg)
Operating Temperature RangeCharge: 0°C to 55°C | Discharge: -20°C to 60°C
Warranty Support2 Years Manufacturer Warranty

Upgrade Your Off-Grid & RV Setup with 3.84kWh Deep Cycle Power

Take full control of your power independence with the reliable GP-12300 battery. Contact the Gobel Power team today for bulk quotes, shipping assistance, and system pairing support.
